Industrial Boom Barrier Gate

TECHNOSPACIO-BOOMBARRIER-1500
Overview

An Anti-Collision Barrier Gate is an advanced vehicle access control system designed to regulate and secure entry and exit points while ensuring maximum safety for both vehicles and equipment. Built with a strong metal structure and intelligent control technology, it provides smooth and fast operation in high-traffic areas such as parking facilities, industrial sites, toll plazas, and commercial complexes. The system is equipped with smart sensing and automatic control features that help detect obstacles and prevent accidental collisions during operation. This makes it a reliable and durable solution for modern security and traffic management applications, combining strength, safety, and automation in a single system.

24V Motor
4 Sec OpenTime
Fast Operation
100% Duty
IP56 Rated
Hydraulic Motor
×
Opening Speed

4

sec

Lifespan

0

Million Cycles

Warranty

5

years

Brand Name TECHNOSPACIO
Model No. TS-B-ACG-500
Size 4000 × 1200 × 500 mm
Drive Mode Built-in Hydraulic Drive Unit
Warning Method STOP Sign
Impact Resistance IWA 14-1:2013, 7200 kg @ 48 km/h (K4-P1)
Working Voltage 380V, 50/60 Hz
Rated Power 3.75 kW
Blocking Width 3–6 m
Lift Speed 3 meters (4–6 Seconds)
Operating Temperature -40°C to +70°C
Device Weight 850 kg
Material Q235 Steel
Shaft & Base Shaft: Aluminum Alloy + Q235 | Base: Q235
Anti-Collision Grade K4 / K8 / K12 – PAS 68
Apartment Entry

Vehicle access control

Industrial Gates

Factory & warehouse control

Parking Systems

Mall & office parking

Toll & Security

RFID & LPR integration

100% Duty Cycle

Designed for continuous operation without overheating

Servo Motor

Energy-efficient 24V motor with planetary gearbox

Heavy Cabinet

2mm rust-resistant iron housing

No Limit Switch

End-position detection without mechanical switches

Adjustable Speed

Variable opening and closing speed control

Dual Springs

Enhanced durability and balanced movement

Left/Right Config

Bi-directional mainshaft installation

×
