Tunnel Size(mm) |
650(L)*500(W) |
Unit Weight(kgs) |
575 |
Conveyor Speed(m/s) |
0.22 |
Conveyor Max Load(kgs) |
200 |
X Ray Leakage |
< 1.0 μ Gy/h |
Wire Resolution |
dia 0.102mm copper wire ( AWG38 ) |
Power Consumption |
max.1KW |
Anode Voltage |
140 KV |
Generate Angle |
80 degree upward |
Cooling/Duty Cycle |
Oil Cooling/100% |
Unit Size(mm) |
2195(L)*902(W)*1362(H) |
Gross Weight(kgs) |
700 |
Conveyor Height(mm) |
695 |
X Ray Dose Per Each Inspection |
2.0 μGy |
Penetration |
32 mm steel |
Spatial Resolution |
Horizontal: dia 1.0 mm Vertical: dia 1.0 mm |
Noise |
< 58 dB |
Anode Power |
0.4-12mA(adjustable) |
Generate Direct |
from bottom to top |
