TS-B-1100
Introduction
Technospacio TS-B-1100 series boom Barrier gate is durable, accurate, flexible and safe. It assembles with aluminum alloy octagonal beam with the Max. Length of 4 m, gate open/close time is 0.9s/1.5s/3s optional TS-B-1100 series boom barrier gate features a 2nd generation DC brushless servo mechanism for compact design, durability, and easy maintenance. It ensures safety with self-locking structure, anti-smashing rebound, and loop detector auto-close. With reduced failure rates, waterproof control board, and precision-molded parts, it delivers stable, reliable, and long-lasting performance.
Professional parking solution
The Parking Pro is the first choice for operators of multi-Story car parks and solution suppliers thanks to its rapid opening times, low operating costs, easy handling, great reliability and extra- ordinarily long service life.
Innovative Drive Technology
Maintenance-free, energy-efficient, and quiet. High torque ensures reliable operation even in extreme weather.
Legal Security
All barriers from TECHNOSPACIO have A conformity declaration in line with the Machinery Directive and a performance declaration according to Construction Products Regulation. operators and installers are always on the safe side regarding liability issues.
Easy Access to Components
Two simple hand movements Suffice easy access to the control system and drive unit by removing the hood and front panel. This increases user-friendliness and also speeds up commissioning and servicing.
100% duty cycle for continuous operation
Energy-efficient 24V brushless motor with planetary gearbox
Rust-resistant iron cabinet, 2.0 mm thickness
End-position detection without limit switches
Adjustable variable speeds
Dual tension springs for enhanced durability
Bi-directional mainshaft, configurable for left or right operation
| Model No | TS-B-1100 |
| Framework Material | Cold-roll sheet, withcolor paint, fullbody 1.5mm ,IP55 level |
| Beam | Aluminum alloy |
| Motor | 800W DCbrush-less Servomotor |
| Mechanical Structure | Adjustable (left or right) |
| Dimension | 505 * 500 * 1400mm |
| Remote Control Distance | ≤30M，＜100m(open,sunny weather) |
| Operating Speed | 3s,6s when starting up the arm |
| Weight | 75KG |
| Power Supply | AC220V/110V, 50/60Hz |
| Working Temperature | -40°C to +85°C |
