Tripod Turnstile


Tripod Turnstile Technical Specification
Model TS-352
Size 1600*240*980mmmm
Unlocking time 0.2s
Passing speed ≤35 people/min
Channel width ≤ 610mm
Voltage input 220V, 50HZ
Fully automatic DC motor 24v/40w
Semi-automatic drive voltage 24v
Ambient temperature -25 ° C ~ +70 ° C
Open the gate signal input dry contact
Packing size 1680*340*1040mm


Tripod Turnstile Technical Specification
Model TS-312
Size 1200*280*980mmmm
Unlocking time 0.2s
Passing speed ≤35 people/min
Channel width ≤ 610mm
Voltage input 220V, 50HZ
Fully automatic DC motor 24v/40w
Semi-automatic drive voltage 24v
Ambient temperature -25 ° C ~ +70 ° C
Open the gate signal input dry contact
Packing size 1280*380*1040mm


Tripod Turnstile Technical Specification
Model TS-314
Size 1200*280*980mmmm
Unlocking time 0.2s
Passing speed ≤35 people/min
Channel width ≤ 610mm
Voltage input 220V, 50HZ
Fully automatic DC motor: 24v/40w
Semi-automatic drive voltage 24v
Ambient temperature -25 ° C ~ +70 ° C
Open the gate signal input dry contact
Packing size 1280*380*1040mm


Tripod Turnstile Technical Specification
Model TS-312
Size 1200*280*980mmmm
Unlocking time 0.2s
Passing speed ≤35 people/min
Channel width ≤ 610mm
Voltage input 220V, 50HZ
Fully automatic DC motor 24v/40w
Semi-automatic drive voltage 24v
Ambient temperature -25 ° C ~ +70 ° C
Open the gate signal input dry contact
Packing size 1280*380*1040mm


Tripod Turnstile Technical Specification
Model TS-238
Size 1000x240x980mm
Unlocking time 0.2s
Passing speed ≤35 people/min
Channel width ≤ 610mm
Voltage input 220V, 50HZ
Magnet voltage 24v/40w
Ambient temperature -25 ° C ~ +70 ° C
Open the gate signal input dry contact
Packing size 1480*380*1040mm
Material 304 stainless steel
Material thickness cover 1.5mm, case 1.2mm


Tripod Turnstile Technical Specification
Model TS-285
Size 1400x240x1000mm
Unlocking time 0.2s
Passing speed ≤35 people/min
Channel width ≤ 610mm
Voltage input 220V, 50HZ
Fully automatic DC motor 24v/40w
Semi-automatic drive voltage 24v
Ambient temperature -25 ° C ~ +70 ° C
Open signal input dry contact
Material 304 stainless steel
Packing size 1680*340*1040mm
