| Technical Specification |
|---|
| Model | TS-703 |
| Size | 3600*1350*2260mm |
| Unlocking time | 0.2s |
| Passing speed | ≤35 people/min |
| Channel width | ≤ 650mm |
| Voltage input | 220V, 50HZ |
| Magnet voltage | 24v/40W |
| Ambient temperature | -25 ° C ~ +70 ° C |
| Open the brake signal input | dry contact |
| Packing size | 2700*1550*2360mm |
| Technical Specification |
|---|
| Model | TS-704 |
| Size | 1500*1350*2260mm |
| Unlocking time | 0.2s |
| Passing speed | ≤35 people/min |
| Channel width | ≤ 650mm |
| Voltage input | 220V, 50HZ |
| Magnet voltage | 24v/40W |
| Ambient temperature | -25 ° C ~ +70 ° C |
| Open the brake signal input | dry contact |
| Packing size | 2500*1550*2360mm |
| Technical Specification |
|---|
| Model | TS-706 |
| Size | 2400*1350*2260mm |
| Unlocking time | 0.2s |
| Passing speed | ≤35 people/min |
| Channel width | ≤ 650mm |
| Voltage input | 220V, 50HZ |
| Magnet voltage | 24v/40W |
| Ambient temperature | -25 ° C ~ +70 ° C |
| Open signal input | dry contact |
| Packing size | 2500*1550*2360mm |
| Technical Specification |
|---|
| Model | TS-718 |
| Size | 2400*1350*2260mm |
| Unlocking time | 0.2s |
| Passing speed | ≤35 people/min |
| Channel width | ≤ 650mm |
| Voltage input | 220V, 50HZ |
| Magnet voltage | 24v/40w |
| Ambient temperature | -25 ° C ~ +70 ° C |
| Open the brake signal input | dry contact |
| Packing size | 2500*1550*2360mm |
| Technical Specification |
|---|
| Model | TS-729 |
| Size | 2400*1350*2260mm |
| Unlocking time | 0.2s |
| Passing speed | ≤35 people/min |
| Channel width | ≤ 650mm |
| Voltage input | 220V, 50HZ |
| Magnet voltage | 24v/40w |
| Ambient temperature | -25 ° C ~ +70 ° C |
| Open the brake signal input | dry contact |
| Packing size | 2500*1550*2360mm |
| Technical Specification |
|---|
| Model | TS-739 |
| Size | 3600*1350*2260mm |
| Unlocking time | 0.2s |
| Passing speed | ≤35 people/min |
| Channel width | ≤ 650mm |
| Voltage input | 220V, 50HZ |
| Magnet voltage | 24v/40w |
| Ambient temperature | -25 ° C ~ +70 ° C |
| Open the brake signal input | dry contact |
| Packing size | 2700*1550*2360mm |
