Products

Sliding Turnstile


Full Height Turnstile Technical Specification
Model TS-209
Size 1400*320*1000mm
Unlocking time 0.2s
Passing speed ≤35 people/min
Channel width ≤ 550mm
Voltage input 220V, 50HZ
DC motor 24v/40w
Ambient temperature -25 ° C ~ +70 ° C
Open the gate signal input dry contact
Packing size 1480*400*1060mm
Full Height Turnstile Technical Specification
Model TS-228
Size 1400*320*1000mm
Unlocking time 0.2s
Passing speed ≤35 people/min
Channel width ≤ 600mm
Voltage input 220V, 50HZ
DC motor 24v/40w
Ambient temperature -25 ° C ~ +70 ° C
Open the gate signal input dry contact
Packing size 1280*420*1060mm

Full Height Turnstile Technical Specification
Model TS-237
Size 1500*320*1000mm
Unlocking time 0.2s
Passing speed ≤35 people/min
Channel width ≤ 550mm
Voltage input 220V, 50HZ
DC motor: 24v/40w
Ambient temperature -25 ° C ~ +70 ° C
Open the gate signal input dry contact
Packing size 1600*420*1060mm


Full Height Turnstile Technical Specification
Model TS-238
Size 1400*320*1000mm
Unlocking time 0.2s
Passing speed ≤35 people/min
Channel width ≤ 600mm
Voltage input 220V, 50HZ
DC motor: 24v/40w
Ambient temperature -25 ° C ~ +70 ° C
Open the gate signal input dry contact
The height of the gate from the ground 1200mm
Packing size 1480*420*1060mm


Full Height Turnstile Technical Specification
Model TS-286
Size 1600*320*1000mm
Unlocking time 0.2s
Passing speed ≤35 people/min
Channel width ≤ 600mm
Voltage input 220V, 50HZ
DC motor: 24v/40w
Ambient temperature -25 ° C ~ +70 ° C
Open the gate signal input dry contact
The height of the gate from the ground 1200mm
Packing size 1480*420*1060mm


Full Height Turnstile Technical Specification
Model TS-631
Size 1400x320x1000mm
Unlocking time 0.2s
Passing speed ≤35 people/min
Channel width ≤ 550mm
Voltage input 220V, 50HZ
DC motor: 24v/40w
Ambient temperature -25 ° C ~ +70 ° C
Open the gate signal input dry contact
Packing size 1480*400*1061mm
