| Technical Specification |
|---|
| Model | TS-238S |
| Size | 1400*160*1000mm |
| Unlocking time | 0.2s |
| Passing speed | ≤35 people/min |
| Channel width | ≤ 610mm |
| Voltage input | 220V, 50HZ |
| Fully automatic DC motor | 24v/40w |
| Semi-automatic drive voltage | 24v |
| Ambient temperature | -25 ° C ~ +70 ° C |
| Open the gate signal input | dry contact |
| Packing size | 1480*260*1060mm |
| Technical Specification |
|---|
| Model | TS-242S |
| Size | 1600*200*1000mm |
| Unlocking time | 0.2s |
| Passing speed | ≤35 people/min |
| Channel width | ≤ 610mm |
| Voltage input | 220V, 50HZ |
| Fully automatic DC motor | 24v/40w |
| Semi-automatic drive voltage | 24v |
| Ambient temperature | -25 ° C ~ +70 ° C |
| Open signal input | dry contact |
| Packing size | 1580*400*1060mm |
| Technical Specification |
|---|
| Model | TS-250S |
| Size | 1640*76*1000mm |
| Unlocking time | 0.2s |
| Passing speed | ≤35 people/min |
| Channel width | ≤ 610mm |
| Voltage input | 220V, 50HZ |
| Fully automatic DC motor: | 24v/40w |
| Semi-automatic drive voltage | 24v |
| Ambient temperature | -25 ° C ~ +70 ° C |
| Open signal input | dry contact |
| Packing size | 1680*200*1060mm |
| Technical Specification |
|---|
| Model | TS-252S |
| Size | 1400*186*1000mm |
| Unlocking time | 0.2s |
| Passing speed | ≤35 people/min |
| Channel width | ≤ 610mm |
| Voltage input | 220V, 50HZ |
| Magnet voltage | 24v/40w |
| Ambient temperature | -25 ° C ~ +70 ° C |
| Open the gate signal input | dry contact |
| Packing size | 1480*285*1060mm |
| Technical Specification |
|---|
| Model | TS-253S |
| Size | 1400*120*1000mm |
| Unlocking time | 0.2s |
| Passing speed | ≤35 people/min |
| Channel width | ≤ 610mm |
| Voltage input | 220V, 50HZ |
| Magnet voltage | 24v/40w |
| Ambient temperature | -25 ° C ~ +70 ° C |
| Open signal input | dry contact |
| Packing size | 1480*220*1060mm |
| Technical Specification |
|---|
| Model | TS-286S |
| Size | 1400*160*1000mm |
| Unlocking time | 0.2s |
| Passing speed | ≤35 people/min |
| Channel width | ≤ 610mm |
| Voltage input | 220V, 50HZ |
| Magnet voltage | 24v/40w |
| Ambient temperature | -25 ° C ~ +70 ° C |
| Open signal input | dry contact |
| Packing size | 1480*220*1061mm |
